AJA Corvid 44-T – Standard-profile 8-lane PCIe, 4 x SDI

AJA Corvid 44-T

The AJA Corvid 44-T is the default version of the Corvid 44 range. This PCIe card is designed to Increase your video and audio I/O capacity. Configure each SDI connection individually as input or output and mix formats for up to 4 HD or SD channels on a single card. As demand rises for higher resolutions, combine SDI connections into a single 4K/UltraHD channel, allowing incredible flexibility and futureproofing.

AJA Corvid 44-T Features

• Up to four independent* bidirectional channels
• 3G-SDI input/output for High Frame Rate (HFR) support
• All 4K/UltraHD/2K/HD/S video formats
• 8 or 10-bit YCbCr and 12- bit RGB frame buffer formats
• 2 independent Mixer/Keyer widgets
• 4 independent 16-Ch 48 kHz SDI embedded audio I/O engines
• Switchable LTC/Reference input connection
• Analog Color Black or HD Tri-level Sync
• 8-lane PCI 2.0 interface
• Full height and half height models
• RS-422 on internal header or bracket (on full height model)
• LTC input on internal header
• Three Year warranty
• 4 Frame stores (In or Out)
• 4 Color space converters
• 2 Mixer/Keyer widgets
• 4 1D LUTs
• 4 Dual Link in
• 4 Dual Link out
• 4 16-Channel embedded audio engines

Specifications

• Video Formats
• (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
• (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
• (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
• (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
• (HD) 1080i 25, 29.97, 30
• (HD) 1080PsF 23.98, 24, 25, 29.97, 30
• (HD) 1080p 23.98, 24, 25, 29.97, 30, 50 A/B, 59.94 A/B, 60 A/B
• (HD) 720p 50, 50.94, 60
• (SD) 625i 25
• (SD) 525i 29.97
• Environment
• Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
• Operating Relative Humidity: 10-90% non-condensing
• Safe Storage Temperature (Power OFF): -40 to 70 degrees C (-40 to 158 degrees F)
• Operating Altitude: <3,000 meters (<10,000 feet)
• Airflow across the board for fanless models
• Video Input Digital: 4 x 3G-SDI BNC
• Video Output Digital: 4 x 3G-SDI BNC
• Audio Input Digital: 16-Channel 24-bit SDI embedded, 48 kHz synchronous
• Audio Output Digital: 16-Channel 24-bit SDI embedded, 48 kHz synchronous
• Size (w x d x h): .875 x 7.25 x 4.875 (22.23mm 184.15mm 123.83mm)
• Weight: 0.4 lb (0.2 kg)
• Power: 17W typical, 19W maximum
